Sale!
FEB 18650H 4000mAh 8A

FEB 18650H 4000mAh 8A

Original price was: $5.78.Current price is: $5.14.

4000mAh high-capacity 18650 with 8A CDR.

400 in stock

SKU: FEB-18650-4000 Category: Tags: , , , ,

FEB 18650 4000mAh 8A

High-energy density cell optimized for long cycle life and stable power delivery.

Technical Specifications

Specification Value
Format 18650
Nominal Capacity 4000mAh
Nominal Voltage 3.6V
CDR 8A (2C)
Chemistry Li-ion NMC
Cycle Life 2000+ deep cycles
Discharge Temp -20C to 60C
Charge Voltage 4.2V
Discharge Cutoff 2.5V

Safety Warning

Unprotected cell. Always use with a BMS. Never short-circuit or overcharge. Keep away from fire and extreme heat. Not for use in e-cigarettes or similar devices.

Cell Specification

Item Specification and comments
Cell model 18650H 4000mAh – cylindrical Li-ion rechargeable cell
Nominal capacity 4000mAh – Charge: 0.5C (2000mA), CCCV, 4.20V, 0.02C (80mA) cut-off; Discharge: 0.2C (800mA) to 2.5V
Minimum capacity 3850mAh – measured under standard charge / 0.2C discharge to 2.5V
Energy density 300Wh/kg
Nominal voltage 3.60V
Internal resistance ≈25mΩ (AC impedance, 1000Hz)
Charge cut-off voltage 4.20V
Discharge cut-off voltage 2.50V
Charging cut-off current ≈0.02C (80mA)
Standard charging current 0.5C (2000mA)
Standard discharge current 1C (4000mA)
Max. charge current 1.0C (4000mA) for 45°C > T ≤ 15°C; 0.5C (2000mA) for 15°C > T ≤ 5°C; 0.1C (400mA) for 5°C > T ≤ 0°C
Max. discharge current 1C (4000mA) for 60°C > T ≤ 45°C; 2C (8000mA) for 45°C > T ≤ 0°C; 1C (4000mA) for 0°C > T ≤ -20°C
Working temperature Charge: 0~45°C; Discharge: -20~60°C
Cell dimension Height: 65.05 ± 0.15mm; Diameter: 18.35 ± 0.15mm
Weight ≈50g

Download Manufacturer data sheet

Battery Safety

Battery Safety & Product Disclaimer

Read before purchasing or using any rechargeable lithium-ion battery.

Rechargeable lithium-ion batteries are high-energy devices that require proper handling and technical knowledge. Improper use can lead to fire, explosion, thermal runaway, serious injury, property damage, or death.

By purchasing products from CH-AmpX, you acknowledge these risks and agree to use all battery products responsibly and in accordance with manufacturer specifications.

Read the Complete Battery Safety Guide

Is This Product Right for You?

CH-AmpX battery cells are intended for:

  • Professional battery pack builders
  • Engineers and product developers
  • Industrial applications
  • Qualified hobbyists familiar with lithium-ion battery technology

These cells are designed to be integrated into battery packs protected by an appropriate Battery Management System (BMS) or Protection Circuit Board (PCB).

They are not intended for standalone consumer use, vaping devices, e-cigarettes, or any application lacking proper battery protection.

Before Every Use

Always inspect every battery before charging, installing, or transporting it.

Do not use any battery that shows signs of:

  • Damaged or torn PVC wrapping
  • Missing insulator ring
  • Dents or crushed casing
  • Swelling or bulging
  • Leakage
  • Corrosion
  • Burn marks or overheating

Using a damaged cell significantly increases the risk of battery failure.

Safe Charging Practices

Battery safety begins with proper charging.

Always:

  • Use a charger designed for lithium-ion batteries.
  • Confirm the charger matches the battery's voltage specifications.
  • Charge on a non-flammable surface.
  • Monitor batteries while charging.

Never:

  • Overcharge or over-discharge a battery.
  • Leave batteries charging unattended.
  • Charge damaged cells.
  • Use incompatible charging equipment.

Safe Storage & Transportation

Improper storage is one of the leading causes of accidental battery incidents.

Never carry loose batteries in:

  • Pockets
  • Backpacks
  • Purses
  • Toolboxes
  • Bags containing metal objects

Contact with keys, coins, tools, or other conductive materials can create a short circuit capable of causing severe burns, fire, or explosion.

Always transport batteries inside protective, non-conductive battery cases.

Store batteries in a cool, dry environment away from excessive heat, moisture, and direct sunlight.

Understanding Thermal Runaway

Thermal runaway is a rapid chain reaction that causes a battery to generate excessive heat, potentially resulting in venting, fire, or explosion.

It may be caused by:

  • Overcharging
  • Short circuits
  • Physical damage
  • Excessive temperatures
  • Internal battery failure

Reducing these risks begins with proper charging, careful handling, and correct battery storage.

Never Do the Following

To reduce the risk of injury or property damage, never:

  • Short circuit a battery.
  • Crush, puncture, or modify the cell.
  • Expose batteries to fire, water, or excessive heat.
  • Charge or discharge outside the manufacturer's specifications.
  • Dispose of lithium-ion batteries in household trash.

Recycle batteries only through approved recycling facilities.

If a Battery Fails

Immediately stop using any battery that becomes unusually hot, swells, leaks, hisses, or emits smoke.

If it can be done safely:

  • Move the battery to a non-flammable surface such as concrete or sand.
  • Keep it away from combustible materials.
  • Allow the battery to cool from a safe distance.

For lithium-ion battery fires, an ABC dry chemical extinguisher may be used. Large amounts of water may also be effective for cooling lithium-ion cells and helping prevent fire spread. Continue monitoring the battery after the incident, as damaged cells may reignite.

If the fire cannot be safely controlled, evacuate the area immediately and contact emergency services.

CH-AmpX Product Disclaimer

CH-AmpX supplies lithium-ion batteries and battery components intended for knowledgeable users and professional battery pack builders.

Customers are responsible for ensuring that all batteries are used, charged, stored, transported, and installed according to manufacturer specifications, industry best practices, and applicable regulations.

CH-AmpX shall not be held liable for any injury, property damage, equipment failure, financial loss, or other damages resulting from:

  • Improper handling or misuse
  • Incorrect charging practices
  • Unauthorized modification
  • Improper storage or transportation
  • Failure to follow recommended safety procedures
  • Use outside manufacturer specifications

By purchasing from CH-AmpX, you acknowledge the inherent risks associated with lithium-ion batteries and accept full responsibility for their safe handling and use.

View Complete Safety Guide
Weight 0.111 lbs
Dimensions 2.561 × 0.722 × 0.722 in
